MasterWatt 550 MasterWatt 550 Fan 12cm, 1 đường 12v 45A, (4+4pin) CPU, 6 sata, 2 ata, 2 PCI Express  6+2 pin, chuẩn ERP 2013 lot 6, Active PFC, hiệu suất đạt chuẩn 80 PLUS bronze , cáp rời S000150 MasterWatt Series 1.710.000 VND Số lượng: 1000 cái

MasterWatt 550

  • Mã sản phẩm: S000150
  • Giá bán: 1.710.000 VND

  • Fan 12cm, 1 đường 12v 45A, (4+4pin) CPU, 6 sata, 2 ata, 2 PCI Express  6+2 pin, chuẩn ERP 2013 lot 6, Active PFC, hiệu suất đạt chuẩn 80 PLUS bronze , cáp rời


  •

Số lượng
Số lượng: 1000 cái

MASTERWATT 550

Semi-fanless Modular
80 PLUS Bronze Certified Power Supply



The MasterWatt is an 80 Plus Bronze power supply with an innovative semi-fanless mode. Under 15% load,the MasterWatt fan remains idle,offering zero dBA. When demand for power increases,a gradual fan curve provides measured cooling with little to no noise at any output level. Dual forward / DC-to-DC topology is employed to keep the voltage stable in all conditions. For increased performance,MasterWatt is equipped with 16 AWG power cables,which reduces resistance,thereby increasing efficiency.
80 PLUS Bronze Certified

The 80 PLUS Bronze certification guarantees that MasterWatt delivers an average efficiency of 85%.
Durable LDB Bearing

Sealant on the bobbin and featuring the highest dustproof level IP6X
Sealant on the The groove outside of the bearing helps to circulate the oil
Recycle slot adds extra storage space for the oil
The shaft makes the oil flow by pumping it while spinning
Cooler Master 120mm Silencio FP fan combines sealed LDB bearings with quiet fan blades offering a long lifetime of quiet cooling.
Semi-Fanless up to 15% load

MasterWatt Operates at 0dB under 15% load. Experience noise-free basic computing.
Dual Forward and
DC-to-DC Circuit Design
More Conductive PCI-e Cables

The Dual Forward and DC-to-DC circuit design offers reliability and stability. This is especially significant in +3.3V and +5V outputs.
The MasterWatt uses 16AWG cables for PCI-e cables. Less resistance and better efficiency,providing you a safer user environment.

Specifications
Product Name MasterWatt 550
Product Number MPX-5501-AMAAB
Type ATX 12V V2.4
PFC Active PFC
Operation Voltage 100-240 Vac
Input Voltage 100-240 Vac
Input Current 8-4 A
Input Frequency 50-60 Hz
Dimensions (LxBxH) 140 x 150 x 86 mm
Fan Size 120 mm
Fan Bearing LDB
Power Good Signal 100-500 ms
Hold Up Time 16ms at 80% load
Efficiency 85% @ Typical Load
ErP 2013 Lot 6 Yes
MTBF >100,000 hours
Operating Temperature 0 ~ 40°C
Protections OCP / OVP / UVP / OPP / OTP / SCP
Regulatory CCC, CE, TUV-RH, RCM, EAC, cTUVus, FCC, BSMI, KC, CB
Connectors MB 24 Pin 1
CPU 12V 4+4 Pin 1
SATA 6
Peripheral 4 Pin 2
FDD Cable 4 Pin 1
PCI-e 6+2 Pin 2
